Allen & Heath | Avantis
Full-size 64-channel / 42-bus digital mixer with Dante
Technical specifications
Technology : Digital mixing console with 96 kHz XCVI FGPA processor
Latency : 0.7 ms fixed
Mixable channels : 64
Mixing buses : 42
DCA groups : 16
Faders : 24
Assignable faders : 144
Effects racks : 12 with dedicated stereo returns
Control : 2x 15.6" Full HD touchscreens
Local inputs : 12 XLR Mic/Line + 1 XLR AES3 (AES/EBU)
Local outputs : 12 XLR Line + 2 XLR AES3 (AES/EBU)
Expansion cards : 1 Dante 64 x 64 + 1 GigaACE 128 x 128
Dimensions W x H x D : 917 x 369 x 627 mm
Net weight : 26.0 kg
Weight in flight case : 74.4 kg
Complementary products
Alternatives
Frequently asked questions
The Avantis is a professional digital mixing console offering up to 64 processing channels, 42 mixing buses and DSP power suited to demanding productions.
It enables up to 64 channels of digital audio to be exchanged over a Dante network, simplifying integration into modern audio infrastructures.
GigaACE provides high-capacity connectivity with Allen & Heath stage racks and consoles while ensuring low latency and high stability.
This console is particularly well suited to live productions, theatres, places of worship, convention centres and professional audiovisual installations.
