ARRI | SkyPanel S60-C

Professional RGBW Soft LED Panel

Technical specifications

Technology : Interchangeable soft diffusion LED panel

Light source : RGBW LED engine

Colour temperature : 2800 K to 10000 K with continuous Green/Magenta correction

Light quality : CRI >95; TLCI >90; CCT tolerance: ±100 K

Colour control : RGBW colour mixing, Hue & Saturation adjustment, calibrated white light modes

Beam angle / Light aperture : 105° / 645 x 300 mm

Dimming : 0–100% continuous, flicker-free operation with no colour temperature shift

Control protocols : DMX512, RDM, Art-Net, sACN and onboard controller

Connectivity : 5-pin XLR DMX/RDM In/Out + 1 EtherCON RJ45 LAN In + 1 USB-A (Firmware Updates) + 1x 3-pin XLR AC Power In + 1x 4-pin XLR DC Battery Input

Mounting system : Aluminium yoke with 28 mm Junior Pin spigot / ±90° tilt adjustment

IP rating : IP20

Power supply : 48 V DC via external PSU or 23-36 V DC battery input

Power consumption : 400 W (max.)

Dimensions W x H x D (without yoke) : 688.2 x 347.0 x 133.0 mm

Weight (head only with diffuser) : 10.6 kg

Weight (manual version with yoke) : 12.6 kg

Complementary products

USB Lighting control surface for MagicQ Software

Compact lighting control console with integrated multitouch display

Professional digital lighting control console

Alternatives

High-Output full-color LED ellipsoidal spotlight

Frequently asked questions

The ARRI SkyPanel S60-C is a professional soft LED panel designed to deliver exceptionally smooth, uniform and colour-accurate lighting. Thanks to its RGBW LED engine, adjustable colour temperature from 2,800 K to 10,000 K and outstanding colour rendition, it meets the demanding requirements of film productions, television studios, broadcast environments and premium live events. Its interchangeable diffusion system also allows lighting characteristics to be adapted quickly to suit any production.

Unlike traditional LED panels designed primarily for white light, the SkyPanel S60-C features a full RGBW engine capable of producing millions of colours while offering precise control of hue, saturation, green/magenta correction and colour temperature. It combines exceptional colour consistency with outstanding flexibility, allowing a single fixture to replace multiple lighting instruments on set.

The SkyPanel S60-C is recognised worldwide for its CRI above 95, TLCI above 90, flicker-free performance and excellent compatibility with professional cinema and broadcast cameras. These characteristics ensure natural colour reproduction, minimise colour correction during post-production and explain why the fixture has become a standard on countless international film and television productions.

The SkyPanel S60-C can be operated directly using its onboard control interface or remotely via DMX512, RDM, Art-Net and sACN. Its EtherCON network connectivity enables seamless integration into professional lighting infrastructures used in film, television, broadcast and live event productions.
