ETC | Source Four LED Series 2 Daylight HD 25-50°

High-definition LED profile fixture with variable zoom

Technical specifications

Technology : Series 2 Daylight HD LED profile fixture

Light source : 60 Luxeon Rebel RMBI LEDs

Manual zoom : 25° - 50°

Colour temperature : 2200 K - 6500 K

CRI : Up to 95

Dimming : 15-bit virtual dimming engine

DMX channels : 6 modes with 6 - 15 channels

Protocols : DMX512-A, RDM

DMX connections : 5-pin XLR In/Thru

Power connections : PowerCON In/Thru

Control modes : RGB, HSI, HSIC, Direct, Studio, Strobe

Protection rating : IP20

Power consumption : 248 W

Dimensions W x H x D : 290 x 850 x 290 mm

Weight without accessories : 13 kg

Complementary products

USB Lighting control surface for MagicQ Software

Compact lighting control console with integrated multitouch display

Professional digital lighting control console

Alternatives

High-Output full-color LED ellipsoidal spotlight

Frequently asked questions

The Source Four LED Daylight HD offers lower power consumption, a significantly longer source life and variable colour temperature without the need for filters. Its RMBI LED engine also provides high-quality white light for broadcast, theatre and event applications.

The Daylight HD version allows precise adjustment of colour temperature from 2200 K to 6500 K, with optimised performance for cool whites and daylight applications.

The Source Four LED Series 2 Daylight HD offers several DMX personalities, including RGB, HSI, HSIC, Direct, Studio and Strobe. Depending on the selected mode, the fixture operates with different DMX channel configurations for intensity, colour temperature, hue, strobe and fan control.

Thanks to its quiet operation, excellent CRI and advanced white-light management, it is particularly suitable for theatres, opera houses, TV studios, broadcast environments, conferences and events requiring high-quality lighting.
