MA Lighting | grandMA2 light

Professional digital lighting control console

Technical specifications

Technology : grandMA2 lighting control console

Integrated control parameters : 4096 parameters (HTP/LTP)

Maximum capacity : Up to 65536 parameters with MA NPU

Motorised faders : 15 executor faders + 2x 100 mm A/B faders

Integrated displays : 2x 15.4" WXGA touchscreens

Control display : 1x 9" SVGA multitouch screen

Local outputs : 6 DMX512-A Out (5-pin XLR), MIDI Out

Local inputs : 1 DMX512-A In, MIDI In, SMPTE, Audio In

Network connections : 2 EtherCON / RJ45 MA-Net2

Additional connections : 5 USB ports, 2x DVI, MA-Link

Network functions : MA-Net2, Multi-User, Tracking Backup

Integrated UPS : Yes

Maximum power consumption : 350 VA

Dimensions W x H x D : 935 x 204 x 652 mm

Net weight : 37.0 kg

Alternatives

Compact lighting control console with integrated multitouch display

USB Lighting control surface for MagicQ Software

Frequently asked questions

The grandMA2 Light provides 8 integrated DMX universes, corresponding to 4,096 control parameters. Its capacity can be expanded using MA Network Processing Units (NPU) to control large-scale lighting systems via the MA-Net2 network.

It offers the same programming tools and software environment as other consoles in the grandMA2 range, in a more compact format than the Full-Size model while maintaining extensive control capabilities.

MA-Net2 enables show data sharing, redundancy, system monitoring and control of multiple MA Lighting devices within a single networked lighting system.

It is commonly used for touring productions, festivals, TV studios, theatres, corporate events and live shows requiring advanced lighting programming and control.
