Shure | ADXR-A
Axient Digital PSM wireless bodypack receiver - 470-636 MHz
Technical specifications
Technology : Axient Digital PSM stereo wireless in-ear monitor bodypack receiver
Carrier frequency range : G56 (470-636 MHz)
Reception : True Digital Diversity with two separate RF signals
Frequency response : 20 - 15000 Hz
Dynamic range : 110 dB(A)
Audio output power : 100 mW at 32 ohms
Minimum load impedance : 2 Ω
Output impedance : < 1 Ω
Frequency rejection : > 80 dB
Squelch threshold : 22 dB SINAD (±3 dB) in analog FM mode
Local output : 1 threaded-locking 3.5 mm TRS mini-jack
Dimensions W x H x D : 68 x 102 x 21.5 mm
Weight without batteries : 124 g
Weight with SB910 battery : 172 g
Complementary products
Alternatives
Frequently asked questions
The Shure ADXR-A is an in-ear monitoring receiver designed to receive audio signals transmitted by Axient Digital PSM or PSM1000 systems and provide high-quality personal monitoring.
It provides excellent audio quality, low latency and strong RF performance, even in high-density frequency environments.
A professional-grade receiver provides stable monitoring, extended dynamic range and accurate reproduction of the monitor mix, which is essential for performers and technicians.
It is particularly suitable for tours, festivals, live shows, television productions and events requiring high-performance wireless monitoring.
